Electrostatic Precipitator
Rationale and Definition
| Company Name | KC Cottrell Co., Ltd. | ||
|---|---|---|---|
| Product Name |
Electrostatic Precipitator
|
||
| Model | |||
| HS Code | |||
| Characteristic |
- With an electrostatic precipitator(ESP), direct high voltage is applied to create corona discharge to charge particles suspended in the gas and collect them through electrostatic attraction. ESP is useful in removing particles in the sub-micron range which are difficult to capture with gravitational or centrifugal force. · Customized system design · Collection with G-Opzel Plate · Dura-Trode discharge electrode · Semipulse and Multipulse for high collection and energy efficiency Wet type ESP has many similarties with the dry type unit in terms of principle and design. Howenver, a basic difference is that the wet type is used in environments where the gas temperature is at or below point. Also, the rapping gear associated with dry units is replaced by an intermittent washdown system using water or other liquids to remove deposits from the collecting plate. Wet type ESP collects particulates that are sticky or suspended in flue gas close to saturation temperature. It can also capture high resistance particulates and substances in a gaseous state. Two standard models of wet type ESP are availabe: Honey Comb Type(vertical flow) and G-Opzel Type(Horizontal flow) - Advantages · Low particulate emission · Excellent collection efficiency for high resistance dust and mist · Effective water film design · Multiple designs of discharge electrode · Comprehensive waste water treatment |
||
| Keyword(Tag) | |||
Field
| Field |
|---|
| 대기 > 공기질 측정/분석 |
Certification
| Certification Type | Certification Year | Certification Type | Certification Year |
|---|---|---|---|
| No Data. | |||
Supply Performance
| Period | Delivery Destination | Delivery Volume |
|---|---|---|
