Low Volume Air Sampler
Rationale and Definition
| Company Name | APM Engineering Co., Ltd. | ||
|---|---|---|---|
| Product Name |
Low Volume Air Sampler
|
||
| Model | PMS-204 | ||
| HS Code | |||
| Characteristic |
- Sampling for PM10, PM2.5 - Designed for U.S. EPA Reference Method for PM10 or PM2.5 - Korea EPA Approval for PM2.5 Standard Method. - Highly accurate, reliable and mechanically simple system - Touch type TFT-Color LCD allows clean picture at direct sun light - Easily download data via USB port - Very low operating cost and maintenance free - Flow Accuracy ±1.5% through Automatic control - Battery Pack(option: for 30th sampling) - Application : TSP, PM10, PM2.5 - Method : Gravimetric - Sampling Time : 0-999 Hours - Filters : 1ea - Filter Size : PTFE, Teflon, Quartz 47mm - Flow Control : Mass Flow Meter With PWM - Flow Control Accuracy : ±1.5% - Pump Pressure / Flow : 800mbar / 40 LPM - Operating Condition : -30℃~-50℃ - Ambient Parameters : Temp: -30~-50℃ / RH: 0~100%RH /P:112~860mmHg - Memory : 4GB USB Memory(Recording Interval : 5min) - Display : TFT Color LCD 5.6 Touch screen - Input Signals(optional) : Wind Speed, Wind Direction - Communication(optional) : RS232, TCP/IP - Power : 100~240 VAC, 50/60Hz(1kwh, 5A) - Weight / Dimension : 18kg / 366mm * 465mm * 250mm - Sound Level : <44dBA(~2m) / <28dBA(~8m) - Language : English, Chinese, Korean - Report Contents(Excel) : Ambient Temp/RH/Pressure, Filter Temp/Pressure, Start/End time, Actual Flow rate & Accumulation, Average, Elapsed time, Events |
||
| Keyword(Tag) | |||
Field
| Field |
|---|
| 대기 > VOC/악취 |
Certification
| Certification Type | Certification Year | Certification Type | Certification Year |
|---|---|---|---|
| PM2.5 sampler and additional equipment | 2014.9.24. |
Supply Performance
| Period | Delivery Destination | Delivery Volume |
|---|---|---|
| - | National Institute of Environmental Sciences | 400 |
| - | Korea Environment Corporation | 400 |
